Site Map widget

The Site Map widget provides a way for people to navigate and explore your digital workplace. The workplace administrator can select the root location of the Site Map widget and it will display all navigable areas of your workplace from there. For example, a Site Map widget could be used to display only the pages and channels that are part of that space. Alternatively, it could show the entire layout of your workplace.

Selecting any of the links in the Site Map widget will bring a person to that page in your workplace.

The Site Map widget on a page.

Sections in this article:

Access and content visibility

Users will only see unhidden locations that they have at least Read access to.

Set up

Follow these steps to set up this widget:

  1. Place a  Site Map widget on a page, space, or dashboard. For more information, see Placing and setting up a widget.
  2. Select the placed widget's Edit button.
  3. Review and make changes to the settings on the Options, Layout, and Appearance tabs. You can find details about the widget's settings in the Settings section below.
  4. In the widget editor, select Update to apply your changes or Cancel to discard them.
  5. At the bottom of your page, space, or dashboard, select Publish or Save as Draft to save your changes.

Settings

Setting Description
Title Enter a title for the widget. The title appears as a heading above the widget's contents. You should use the title to provide context to the widget and better structure a page's content by clearly denoting different sections.

When entering a title, you do so only for your currently selected language. If your digital workplace supports multiple languages, you should select  Translation and enter a title for each supported language.

This field can contain a maximum of 140 characters.
Description

Enter a description for the widget. The description appears between the title and the widget's contents. You can use this text to provide information to users about the widget.

When entering a description, you do so only for your currently selected language. If your digital workplace supports multiple languages, you should select  Translation and enter a description for each supported language.
Source

Select a page or space. The published widget initially displays the channels, pages, and spaces immediately below the selected page or space. Users can then expand and browse locations below this initial list.

Access rules determine what users will see when configuring and viewing the widget:

  • Users who configure this widget will only see pages and spaces that they have at least Read access and are beneath locations that they have at least Read access to.
  • Users who view the published widget will only see locations to which they have at least Read access.
Options tab
Setting Description
Class Enter CSS class selectors to provide additional styling to the widget. For more information, see Applying custom CSS to widgets.
Height Select the height of the widget. Options include:
  • Auto:The leftmost slider position. The height of the widget will increase and decrease to contain what it is displaying.
  • Fixed: Select a fixed height between 50px to 600px in increments of 50px. A vertical scrollbar will appear on the widget if the content exceeds this fixed value.
Appearance tab

Note

Your digital workplace's theme overwrites many of the settings on the Appearance tab. However, the settings listed above are usable.
